Steering and power supply

ERO-32MN1 and 2

ERO-32MN-1 and ERO-32MN-2 controllers are designed for motor speed steering of devices equipped with brushless (BLDC type) motors produced by DARCO and as regulated 0-5 V DC / 0-10 V DC general purpose voltage sources.

ERO-32MN is available in two versions – square (ERO-32MN-1) and round (ERO-32MN-2) and two colour versions – white (B) and black (CZ). ERO-32MN1 and 2 can be mounting – for surface and under surface. Controller is compatible with devices produced by DARCO:

Controller can steering devices produced by other producers 0-5 V DC / 0-10 V DC general purpose voltage sources.

Type ERO-32-MN1 ERO-32-MN2
Voltage [V DC] 20-24
Nominal power [W] 0,6
Max current [mA] 40
Max R output load [mA] 5
IP protection class IP40
Ambient temperature [°C] -20 – +60
Humidity [%] 0 – 80
Measurments [mm] 84 x 84 x 49 85 x 85 x 44
Weight [g] 130 150

Steering and power supply

Electronic dividiers

Dividers are devices enabling convenient distribution of powering voltage or signals for the Hybrid Turbowents.

Electronic power dividier ERZ-06D-0 is device enabling convenient distribution of powering voltage to individual Hybrid Turbowents. A maximum of four (or five if the wire is terminated) devices may be connected to a single divider. Is compatible with:

Junction box TU-HYB-PUSZKA  enabling convenient distribution of signal from the Hybrid Turbowents NET type. A maximum of four, and if the bus is terminated, five devices may be connected to a single box.

Electronic power dividier ERZ-06D-0

Product code Input (WE) Output (WY) Outputs (U1, U2, U3, U4)
Power [V DC] Current [A] Power [V DC] Current [A] Power [V DC] Current [A]
ERZ-06D-0 25 10 25 10 25 2,5



Junction box TU-HYB-PUSZKA

Product code Input (LINE) Output (LINE) Outputs (OUT1, OUT2, OUT3, OUT4)
Power [V DC] Current [A] Power [V DC] Current [A] Power [V DC] Current [A]
TU-HYB-PUSZKA 25 10 25 10 25 2,5

Steering and power supply

Converter

TU-HYB-KONW-USB converter is used to change the Hybrid Turbowent NET interface.

TU-HYB-KONW-USB converter is used to change the Hybrid Turbowent NET interface to the one supported by a PC computer (USB). Managing software as well as necessary drivers may be downloaded from the “Download” tab.

Product code Interface
TU-HYB-KONW-USB USB 2.0

Steering and power supply

Electronic power suppliers EZN

Electronic power suppliers are used as power supply of Hybrid Turbowents (depending on their type).

Presented devices are used as power supply for 1 to 8 pieces of Hybrid Turbowents (depending on their type). They are to be mounted on a TS-35 rail, in ESR type cabinets, with controllers. Electronic power suppliers are compatible with:

Product code Output parameters Max ambient temp.  [°C]
Power [V DC] Nominal power [W] Max current [A]
EZN-010M-0 24 10 0,42 60
EZN-030M-0 30 1,25
EZN-060M-0 60 2,5



Product code Usage / maximal mount
TH150T TH150 TH200 THP200-350
EZN-010M-0 max 1 max  1 max 1
EZN-030M-0 max 3 max 3 max 3
EZN-060M-0 max 8 max 8 max 8 max 1

Steering and power supply

Electronic power supply cabinet ESZ-Z-0

Most convenient way of providing power supply to a group of Hybrid Turbowents is to use an electronic power supply cabinet ESZ type.

Each version of ESZ Z-0  is equipped with connection terminals: one input for 230 V AC and five outputs for 24 V DC; they are also provided with required protection measures: against short-circuit, overvoltage, overload. Individual models differ in terms of the power supply unit used (while retaining the same external dimensions). Selection of a specific device depends on the type and number of connected cowls. Use the “Wiring Calculator” programme available freeware [download Wiring Calculator] or ask a DARCO technical advisor for assistance.

Electronic power supply cabinet ESZ Z-0 is compatible with:

Product code Dimensions [mm] Output parameters Max ambient temperature [°C]
Power[V DC] Nominal power
[W]
Max current [A]
ESZ-060Z-0 300 x 400 x 200 24 60 2,5 40
ESZ-120Z-0 120 5
ESZ-240Z-0 240 10
ESZ-480Z-0 480 20





Steering and power supply

Control cabinet NET version

NET power supply cabinets are equipped with two terminals used to connect the buses of Hybrid Turbowents NET type.

Individual models TU-SZROZ differ in terms of dimensions and power supply unit used. Cabinets are equipped with protective measures: against short circuit, overvoltage and overload; they are intended for outdoor or inside building mounting.

TU-SZROZ are compatible with all Hybrid Turbowent NET version.

Product code Dimensions [mm] Output parameters Max amount of Hybrid Turbowent NET
Power
[V DC]
Nominal power [W] Max current [A]
TU-SZROZ-0 300 x 200 x 160 24 60 2,5 7
TU-SZROZ-I 400 x 300 x 200 240 10 29
TU-SZROZ-II 500 x 400 x 200 480 20 59

Steering and power supply

Radio switches single channel

Signal receivers are used to wirelessly switch on and off following devices.

SignalControllers may operate in five modes:

  • Bistable – device is alternately switched on and off using a single button.
  • Time control – pressing the button causes device to switch on for a time period programmed by the user, after which it is switched off again.
  • Switch On – device is switched on when the button is pressed.
  • Switch Off – device is switched off when the button is pressed.
  • Monostable – device is switched on for the time when button remains pressed (this mode is not recommended). receivers are used to wirelessly switch on and off following devices.

Switching controlled devices on and off:

Product code ROM-01 ROP-01
Mounting on TS-35 rail under surface
Voltage [V / Hz] 230/50
Nominal power [W] 0,45 0,29
Transmission [MHz] 868, 32

Steering and power supply

PRO Remote control

PRO-type remote controls are intended to replace mobile phone, tablet or PC computer in communication with the ERO-32WS-0 controller.

PRO-type remote control allows to increase and decrease rotating speed of the controlled device in a simple way. Also various different functions may be assigned to remote control buttons, i.e.:

  • incremental increase of rotating speed
  • setting a fixed value of rotating speed
  • switching the controlled device on and off

Remote control is compatible with smart building solutions offered by the company BleBox. Is compatible with ERO-32WS-0 control.

Product code PRO
Transmission [GHz] 2, 4
Power supply Lithium polymer battery
Charging Standard micro USB charger
